Nissan Patrol UFI TD42 Turbo Upgrade

Specifically designed & built to suit the Nissan TD42, utilising the factory T3 style flange – same as the factory TD42 turbo. The included dump pipe is designed & manufactured to suit most aftermarket 3″ exhausts

Aftermarket Performance Turbo

United Fuel Injection (UFI) strives to provide better quality of service to a growing number of vehicle owners and enthusiasts in Western Australia. In line with this commitment, we developed a high performance modification to suit the Nissan Patrol TD42 factory turbo vehicles.

Designed to achieve the maximum torque and power from the TD42T and Ti engines, this upgrade provides great value for money.

This process involves replacing the TD42 factory turbo with an aftermarket Mitsubishi TD05. We select and modify the replacement engine to meet the application’s low torque requirement and the extra driveability that comes with that. This upgrade is not application specific and can be fitted to any combination of intercooled or non-intercooled TD42.

Turbo recommended power capacity.

• TD05-16G = Suitable up to 200HP
• TD05-18G = Suitable for 200-230HP
• 21L = Suitable for 250-280HP (IF POWER GOAL IS 250HP, PLEASE SELECT THIS TURBO)
• 23L = Suitable for 280HP-330HP

A High mount ‘Merge’ Type manifold is highly recommend for the 21L & 23L Turbocharger – Using a log or factory manifold will reduce the response of larger turbochargers.

Includes the following:

• Nuts
• Oil lines
• Hose clamps
• Radius Fabrications 3″ Dump Pipe with EGT Bung

The turbo does NOT include a gasket for in between the rear housing and dump pipe. The two surfaces are machined perfectly flat and do not require a gasket. We recommend a thin layer of RTV on the dump flange when installing.

NOTE: Dump Pipes are only supplied for factory manifold and Radius manifold configurations if you have another brand of manifold you will be supplied with a flange to have a dump made up to suit your configuration
